The mobile concrete crusher adopts construction waste treatment technology to produce various types of new building materials that meet the quality inspection specifications. It can turn buliding waste into wealth and protect the environment. It is an im
The mobile concrete crusher adopts construction waste treatment technology to produce various types of new building materials that meet the quality inspection specifications. It can turn buliding waste into wealth and protect the environment. It is an im
After the construction waste crusher plant crushes urban waste, the waste is sorted, removed and crushed by express delivery. Most of them can be reused as renewable energy, such as waste building steel bars, waste fine iron wires, waste cables and various waste steel materials.
1. Metal materials such as spare parts can be reprocessed and processed into stainless steel plates of specifications after sorting, centralization, and re-refining by express delivery.
2. Waste bamboo and wood can be used to produce synthetic wood.
3. Waste such as bricks, stones, and concrete After crushing, it can replace sand and be used as masonry mortar, plastering mortar, foundation cushion, etc., and can be used to make decorative building materials such as aerated blocks, paving bricks, and lattice partition bricks.
Improve the utilization rate of equipment and change the working site at any time
Save production costs and reduce the high cost of construction waste transportation.
Good mobility, compact structure, no need for special transport vehicles.
It is convenient for supporting installation and saves the basic cost of installation and manpower for installation and adjustment.
Construction waste mobile crushing plant is composed of mobile frame, vibrating feeder, construction waste special crusher, screening machine, belt conveyor, iron removal equipment, electric control system, etc. It is also possible to combine configurations according to customer requirements.
The raw materials are directly sent to the silo by the loader, and enter the vibrating feeder from the silo. The vibrating feeder sends concrete evenly to the special crusher for construction waste crushing. The crushed material is sent by the belt conveyor through the iron remover to send to vibrating screen. The crushed material is classifed to different sizes by vibrating screen. Coarse aggregate (10-20mm, 20-30mm) can be used for filling soil, paving base material, concrete, asphalt aggregate. Fine aggregate (0-5mm, 5-10mm) can be used for unburned bricks, eaves bricks, mortar raw materials, cement composites, etc.
| Model | Vibrating feeder | Jaw crusher | Vibrating screen | Belt conveyor | Capacity | Power system | Chasis |
| SKPZ46-1548 | ZSW850X3000 | PE400X600 | 3YK1548 | B650x10 X 3sets | 15-60 TPH | Electrical Control or Generator
Set according to Jobsite |
Tracked mobile，wheel
mobile type,or skid frame |
| SKPZ57-1848 | ZSW960X3800 | PE500x750 | 4YK1848 | B650x10 X 4sets | 50-100 tph |
*The output will vary according to different materials, feed particle size and other factors
