Mobile impact crusher plant is easily movable and transferable crushing machines used to reduce the size of rocks and other materials in aggregates production, recycling applications and in mining operations. It produces good shaped cubical products.
Mobile impact crusher plant is easily movable and transferable crushing machines used to reduce the size of rocks and other materials in aggregates production, recycling applications and in mining operations. It produces good shaped cubical products.
There are two kinds of mobile impact crusher, crawler type and tire type. Different types of stationary impact crushers can be configured as required, or they can be mounted on the same vehicle together with the vibrating screen to realize the integration of crushing and screening. According to the working structure, which configuration should be selected, the user can consult Baichy engineer online, and we can provide you with model selection and crushing plant planning services for free.
The mobile impact crusher does not need to make concrete foundation. It can be pulled and moved and be used immediately. The tire-type mobile impact crusher is pulled by a semi-trailer,which is convenient for narrow sites. Crawler-type mobile impact crusher plant can move by itself, and it can be remotely controlled. Compared with wheel type, the transition mobility is more flexible;
You can also choose a single impact crushing machine, or an integrated configuration of impact crushing and screening plant. The mobile impact crusher can also work together with other mobile equipment, and multiple units can work in parallel to form a graded crushing and mobile crushing production line.
The mobile impact crusher can be used alone, but if the particle size of the raw material is too large, it is usually used in combination with the mobile jaw crusher.
Automatic lubrication system.
Incorporated design. It has high standard requirements on steel structure and high strength wear-resistance parts to crush even hardest rocks(400Mpa)
With support legs on truck,quick to set-up. The supporting legs height can be adjustable, adopt hydraulic controling parts.
Due to its stong structure, truck mounted and easy to move.
How mobile impact cruhser plant works? In the mining and quarry industry, mobile impact crusher plant is usually as secondary crushing machine to process rocks or ores from priamry jaw crusher plant. After impact crusher machine crushing, precisely shaped cubical end products is feed to vibrating screen to get different size material, 0-5mm, 5-10mm, 10-20mm, 20-40mm or some other required size. Vibrating screen is designed to be same level with impact crusher. The oversized material from first layer could be fed to impact crusher directly to crush again. Other required size is sent to stock ground by belt conveyor. Compared to stationary stone crusher plant, iIt has good mobility and can extend together with the raw materials site or construction site and has many types of combinations to satisfy the processing needs of different materials.
| SMC Impact crusher | SMC1010PFS | SMC1210PFS | SMC1214PFS | |
| Transport size | ||||
| Length(mm) | 10800 | 12200 | 12500 | |
| Width(mm) | 2480 | 2743 | 2900 | |
| Height(mm) | 4170 | 4200 | 4200 | |
| Alex weight(kg) | 15900 | 17200 | 22100 | |
| King pin weight(kg) | 11300 | 14300 | 17500 | |
| Impact crusher | ||||
| Model | PF1010 | PF1210 | PF1214 | |
| Feed opening(mm) | 400X1080 | 400X1080 | 400X1080 | |
| Vibrating screen | Vibrating screen | |||
| Model | 4YK1235 | 4YK1545 | 4YK1548 | |
*The output will vary according to different materials, feed particle size and other factors
