Stone crusher is to break blocks of stone, mining ores, concrete and other building materials into a smaller specific grain size. It has types of jaw crusher, cone crusher, impact crusher, hammer crusher, sand crusher, mobile crusher machine etc.
Feed Size : 100mm-1200mm
Motor Power : 5.5-280KW
Processing capacity : 5-800t/h
Stone crusher is to break blocks of stone, mining ores, concrete and other building materials into a smaller specific grain size. It has types of jaw crusher, cone crusher, impact crusher, hammer crusher, sand crusher, mobile crusher machine etc.
Feed Size : 100mm-1200mm
Motor Power : 5.5-280KW
Processing capacity : 5-800t/h
The stone crusher is the processing equipment in the stone production line. Whether its selection is reasonable or not directly affects the production capacity of the project, the quality of the finished material and the return on investment of the customer. So how can we choose the right stone crusher?
1.First of all, correctly understand raw material properties. The physical properties of stone mainly include three aspects: hardness, size, and wet viscosity. The properties are different, and the types of stone crushers to be used are also different, otherwise the expected crushing effect cannot be achieved.
2.Requirements for production capacity, finished product specifications and grain type。The output is also an important indicator to determine the stone crusher equipment. The output of the stone crusher is generally calculated by hour。customer needs to choose according to his own actual situation. If the output is too large, it will cause unnecessary power consumption and operating costs; if the output is too small, it will not be completed. Production goals affect project progress and benefits.
3.The requirements for the specification and grain shape of the finished product are equally critical. The specification of the finished product is directly related to product positioning and is generally determined by the market. If the specifications are large, it is enough to use coarse crushing and medium crushing equipment, such as jaw crushers, impact crushers, and single-cylinder hydraulic cone crushers. If the specifications are small, vertical shaft impact crushers and multi-cylinder hydraulic cone crushers should be added.
4.Be sure to have a full understanding of the construction site。 The specific situation of the construction site is an important factor affecting the selection and layout of crusher equipment. For example: the size of the construction site, the height of the drop, the approximate distance from the raw materials, whether there are residents nearby, etc., are all related to the selection and layout of the equipment.
Heavy-duty designed stone crusher frame. It crushes rocks, other hard and abrasive materials in highly efficiency. High productivity low maintenance and operating costs.
According to material abrasiveness and hardness factor, dimensions, finished grain size, capacity, suitable stone crusher type could be offered.
Primary crusher reduces the raw material to 150 mm around, then secondary or tertiary crushers depending on the size requirement.
MGM stone crushers are exported to Indonesia, Philippine, Malaysia, Saudi Arabic, Kenya, South Afica, Chile, Peru and over 30 countries around the world.
Stone crushing machine is to reduce the size of large rocks to gravel, or grind rocks to table salt size, or even pulverize to a fine powder. Stone crushers are classified and chosen according to the fineness with which they starts material.
Jaw crusher is a machine for crushing rocks and other hard and abrasive materials, such as granite, ores or recycled concrete usually for industrial purposes.
Cone crusher breaks stone between an eccentric rotating head and a bowl. It has ability to crush hard and abrasive ores and rocks. Cone crusher is better suited for secondary crushing.
Impact crusher can be used as primary crushers, secondary crushers or tertiary crushers depending on the size and technology. The impact makes it possible to better control the size of the crushing result, for example better cubic gravel.
| Model | Feeder Opening
Size(mm) |
Max. Feeding
Size (mm) |
Outlet adjusting
Size(mm) |
Capacity
(t/h) |
Motor Power
(kw) |
Overall Dimension
(mm) |
| PE400x600 | 400×600 | 350 | 40-90 | 15-60 | 30 | 1700x1750x1680 |
| PE500x750 | 500×750 | 425 | 50-100 | 40-130 | 45 | 2150x1900x1950 |
| PE600x900 | 600×900 | 500 | 60-125 | 90-180 | 55 | 2500x2010x2350 |
| PE750x1060 | 750×1060 | 630 | 60-150 | 110-380 | 110 | 2630x2310x3110 |
| PE900x1200 | 900×1200 | 750 | 95-165 | 220-450 | 132 | 3720x2850x3250 |
| PE1000x1200 | 1000×1200 | 850 | 200-300 | 280-560 | 160 | 3820x2850x3250 |
| PE1200x1500 | 1200×1500 | 1020 | 150-300 | 400-800 | 220 | 4590×3342×3553 |
| PE1500x1800 | 1500×1800 | 1200 | 210-360 | 520-1100 | 280 | 5100x4700x4300 |
| PEX150x750 | 150×750 | 120 | 10-40 | 5-16 | 15 | 1310x1118x1145 |
| PEX250x750 | 250×750 | 210 | 15-50 | 15-30 | 22 | 1440x1751x1515 |
| PEX350x750 | 350×750 | 300 | 15-50 | 18-40 | 30 | 1485x1680x1648 |
| PEX250x1000 | 250×1000 | 210 | 15-60 | 15-52 | 30 | 1730x1950x1400 |
| PEX250x1200 | 250×1200 | 210 | 15-60 | 20-60 | 37 | 1730x2150x1400 |
| PEX300x1300 | 300×1300 | 250 | 25-60 | 30-105 | 55 | 2000x2320x1730 |
*The output will vary according to different materials, feed particle size and other factors
